Tolerance lines can be displayed in working process report. Use tolerance lines to highlight certain areas in the working process report.

There are 4 different tolerance line styles:

Parameter	Description
Constant	Tolerance line is displayed consistently for a value.
Relative	Tolerance line is displayed in proportion. The proportions can be freely selected.
Constant mirrored	Tolerance line is displayed consistently for a value and mirrored.
Relative mirrored	The tolerance line is displayed in proportion and mirrored in its area. The proportions can be freely selected.

You can additionally set the axis scaling of the x-axis manually. If you do not enter a value, scaling will be implemented automatically.

Select menu Reports > Configure and the desired mode.
Click the desired report configuration.
In the respective chart, select the desired parameters for the respective series.
Click button More in the respective series.
Set the desired tolerance lines and save the changes.
Click button Preview.
